Images are exemplary.
Wire end sleeve pre insulated, DIN 46228 T4, 0.75mm²
Dispenser
Type AH, for fine-stranded copper wires, dispenser
Article Number : AH-005649
In stock
Dimensions
| d1 (Ø) |
1.3 |
|---|---|
| d2 (Ø) |
2.8 |
| L1 (mm) |
14.5 |
| L2 (mm) |
8.0 |
| R1 (mm) |
3.60 |
Technical characteristics
| Length (mm) |
8.00 |
|---|---|
| Wire section (mm²) |
0.75 |
| Wire section (AWG/MCM) |
20 |
| Version |
French color code (Telemecanique) |
| Colour |
Light blue |
| Colour |
|
| Material |
Copper |
| Surface |
tin plated |
| Insulation material |
Polypropylene (PP) |
| Max. temperature (°C) |
+105 |
| UL 486F No. |
E485383 |
| CSA No. |
242724 |
| Standards |
DIN 46228 T4 |
| Packing |
Dispenser 150 x 150 x 18mm |
| Manufacturer |
GLW GmbH |
Download Product Information
